UV-5RM

Product Overview:

1. Product Name: UV-5RM
2. Product Category: Portable Two-Way Radio
3. Main Functions:
   Dual PTT Dual Band Walkie Talkie, VHF UHF Dual Standby, 128CH, CTCSS DCS, VOX, PC Programmable, FM Radio & Flashlight.
4. Main Specifications/Technical Parameters:
   Transmitter Bands: TX 136–174MHz (VHF), 220–260MHz, 400–480MHz (UHF)
   Receiver Bands: RX FM 65–108MHz, Aviation AM 108–136MHz, 136–174MHz, 220–260MHz, 350–390MHz, 400–520MHz, NOAA Weather Band
   Channel Capacity: 640 Channels (Supports Packet Zones)
   Channel Spacing: 25kHz (Wideband) / 12.5kHz (Narrowband) Narrow)
   Output Power: Standard Version: 5W / 1W Plus Version: 10W / 5W / 2W (3 adjustable levels)
   Operating Voltage: DC 7.4V
   Battery: 2500mAh Lithium Battery, USB-C Charging + Dock Charger Dual Modes
   Frequency Stability: ±2.5 ppm
   Antenna Impedance: 50Ω, SMA-F Female Antenna Interface
   Audio Output: 0.75W @16Ω
   Receiver Sensitivity: 0.25μV (12dB SINAD)
   Accessory Interface: Kenwood 2Pin K-type connector (universal Baofeng accessories)
   Display: 1.5-inch Color TFT Screen
   Operating Temperature: -10℃ ~ +60℃
   Dimensions (excluding antenna): 135 × 63 × 39 mm
   Weight (including battery, excluding antenna): Approx. 290g
   Features
5. Multi-band Transmit & Multi-band Receive
   Transmit: VHF 136–174MHz + 220–260MHz + UHF 400–480MHz
   Receiver: Additional support for Airband, NOAA Weather Channel, and FM radio, suitable for outdoor HAM enthusiasts
6. Dual Standby: Simultaneously monitors two frequency groups.
7. One-key Frequency Copy: A major selling point; quickly copies frequencies between two devices without a computer.
8. Color TFT Display: Supports manual keypad frequency input.
9. Memory Channels: (Standard version typically has 640 channels, divided into 10 channel zones).
10. CTCSS/DCS Anti-Crossing: Supports sub-tone scanning.
11. Adjustable Power: Commonly 5W/1W; UV-5RM Plus version up to 10W.
12. VOX Hands-free: No need to press PTT when using headphones.
13. FM Radio: FM Radio, LED LED Flashlight
14. PC Programmable, supports batch settings via CPS programming software
15. DTMF Encoding, ANI Call Sign DTMF/ANI ID, suitable for team scheduling
16. Repeater Access (Frequency Difference, Frequency Inversion)
17. Safety Protection Functions
    TOT Transmission Time Limit, BCLO Busy Channel Lock, Battery Save, Keypad Lock, Emergency Alarm, Wide/Narrow Band Switching
18. UV-5RM Plus GPS Version Additional Features: GPS Positioning, Location Sharing, Teammate Location Viewing
19. Charging: USB-C Charging (New Standard)
20. Supporting Functional Parameters
21. Sub-tone Code: 50 CTCSS + 105 DCS, supports sub-tone scanning
22. Standby Mode: Dual Standby
23. Programming Method: PC CPS Programming + One-key Copy Frequency
24. Modulation Mode: 16K0F3E / 11K0F3E (Wide/Narrowband)
25. Additional features: VOX voice control, DTMF/ANI, TOT transmit timeout, BCLO busy lockout, power saving mode, keypad lock, emergency alarm, LED flashlight
