UV-82
Main functions: Dual PTT Dual Band Walkie Talkie, VHF UHF Dual Standby, 128CH, CTCSS DCS, VOX, PC Programmable, FM Radio & Flashlight.
Contact Us for Pricing
Interested in this product? Contact us now for detailed pricing and product information.
Product Details
Product Overview:
- Product Name: UV-82
- Product Category: Ham Radio
- Main Functions:
Dual PTT Dual Band Walkie Talkie, VHF UHF Dual Standby, 128CH, CTCSS DCS, VOX, PC Programmable, FM Radio & Flashlight. - Main Specifications/Technical Parameters:
General Parameters
Frequency Range: VHF 136-174MHz/UHF 400-520MHz (Dual Band)
Operating Voltage: DC 7.4V (Rechargeable Lithium Battery)
Antenna Impedance: 50Ω
Stored Channels: 128
Dimensions: 115.556.834.5mm
Frequency Stability: ±2.5ppm
Operating Mode: Same Frequency Simplex or Different Frequency Simplex
Operating Temperature: -20℃~+50℃
Grounding Method: Negative - Transmitter Section
- RF Power: 5W Adjacent Channel Power: ≦-65dB/≦-60dB
- Transmit Current: ≦1.5A
- Maximum Frequency Deviation: ≦5kHz/≦2.5kHz
- Modulation Method: FM
- Pre-emphasis Characteristic: 6dB per octave
- Signal-to-Noise Ratio: ≧-45dB/≧-40dB
- Modulation Sensitivity: 8-12mV
- Receiver Section
- Receiver Sensitivity: -122dBm (12dB SINAD)
- Clutter Suppression: >65dB
- Intermodulation Immunity: ≧65dB/≧60dB
- Audio Distortion: <10%
- Audio Power: 1W
- Receiver Current: ≦380mA
- Standard Package: Antenna, Lithium-ion Battery, Power Adapter, USB Smart Charger, Belt Clip
- Optional Packages: Headphones, Microphone, Programming Cable
- Features
- Operating Frequency Band: FM 65-108MHz (Receive) VHF 136-174MHz (receive/transmit) or UHF 400-520MHz (receive/transmit)
- Frequency Mode/Channel Mode
- Digital Tuning FM Radio
- Dual-Band, Dual-Display, Dual-Slot Standby
- Dual PTT Key Transmit
- U/V Band Repeater Cross-Band Transmission
- DTMF Dual-Tone Multi-Frequency Encoding
- Chinese/English Voice Announcement
- Emergency Call Alarm
- CTCSS Editable from 60.0Hz to 259.9Hz
- CTCSS, DCS Automatic Search
- Transmission Timeout Limit
- 6-Step Frequency Adjustment
- 0-9 Level Squelch Selectable
- High/Low Power Switching
- Wide/Narrow Band Function
- Power Saving Mode
- VOX Voice-Activated Transmit
- Busy Transmission Disable Function
- Low Voltage Indicator
- Automatic Backlight
- Automatic Keypad Lock
